Electrode Tube of Dia0.2mm

I. Name: Brass Tube for Drilling EDM Machine

II. Item No: T-D-BT-02

III. Features:

1.      Higher accuracy;

2.      Higher rigid;

3.      Lower wear off rate.

IV. Specification

1. Diameter：0.2mm,

2. Length: 200mm

3. Type: single hole

4. Material: Cu65

5. Tolerance of Dia.: +0/-0.02mm

6. Package: 50 pieces in a plastic tube

V. Usage: Electrode tube  is used for spinneret holes drilling, engine oil nozzle drilling, and aerospace engine air coolant hole drilling on Small Hole EDM machine.
